The Metravi CE-0303 EML Digital kWh Meter is a microprocessor-based device designed for precise energy measurement in both three-phase and single-phase systems. Equipped with a user-friendly 16x2 lines backlit LCD, this meter offers clear visibility for readings even in low-light conditions. It includes advanced features like options for run hour or real-time clock display, and it maintains a high accuracy level of 1%. Built for both LT (Low Tension) and HT (High Tension) systems, this kWh meter is a reliable choice for monitoring energy consumption in industrial and commercial settings.
Key Features:
- Microprocessor-Based Design: Ensures accurate and efficient energy measurements.
- Backlit LCD Display: 16x2 lines display for easy reading of consumption and meter status.
- Accuracy: High precision with 1% accuracy in readings.
- User Programmable CT/PT Ratios: Allows for easy configuration and direct reading adjustments.
- Password Protection: Secures the configuration of CT/PT ratios to prevent unauthorized changes.
- Versatile Compatibility: Available for both 415V LT and 110V HT systems, suitable for 1A and 5A CT secondary.
- Auxiliary Power Supply: Compatible with 230V AC 50Hz or 110V AC 50Hz power inputs.
- Display Options: Toggle between run hour or real-time clock for flexible monitoring.
Specifications:
- Model Number: CE-0303 EML
- Display: 16 x 2 lines backlit LCD
- Accuracy: 1%
- Size: 96 x 96 mm Bexel
- Input Voltage: 415V (LT) and 110V (HT)
- Current Ratings: Suitable for 1A and 5A CT secondary
- Auxiliary Power Supply: 230V AC 50Hz / 110V AC 50Hz
- Programmability: User programmable CT/PT ratios with password protection
Applications:
- Industrial Energy Management: Ideal for tracking and managing energy consumption in industrial settings.
- Commercial Energy Monitoring: Suitable for commercial buildings and facilities requiring precise energy usage tracking.
- Energy Audits: Provides accurate data for energy audits and helps in identifying potential areas for energy saving.
The Metravi CE-0303 EML Digital Three Phase kWh Meter offers advanced features for reliable and precise energy measurement, making it a valuable tool for both industrial and commercial energy management needs.
